SPEETEC
Capture Motion.
Without Contact.
- Optical sensors avoid damage to, and contamination of the surfaces being measured and ensure a high product quality
- Slip-free measurement increases the measurement accuracy thereby optimizing productivity and process quality
- High measurement accuracy, including in start-stop operation and at short measurement lengths
- Easy to incorporate into existing applications thanks to the standardized encoder interface and compact dimensions
- Rugged and maintenance-free
settings_remote
device_hub
straighten
Working Distance
Speed Range
Interface
12 ... 30 VDC, TTL or HTL
50mm / + 5mm
> 0 m/s .... 10 m/s
zoom_in
games
Accuracy
Repeatability
Measurement Step
Max 4 µm
> 0.10%
> 0.05%
Your Benefits
- High measurement accuracy and reproducibility, including in start-stop operation and at short measurement lengths
- Optimized productivity and process quality through measurement without slippage
- Broad range of applications thanks to compatibility with many materials, colors and surfaces
- The class 1 laser saves costs as no additional laser protection measures are required
